C8S46A - Встроенный коммутатор SAN Brocade 16 Гбит / с

Dimensions & Weight

Depth

7.6 in

Height

1.1 in

Weight

3.31 lbs

Width

10.6 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Humidity Range Storage

5 - 95% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

140 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-22 °F

Header

Brand

Brocade

Compatibility

PC

Manufacturer

Hewlett-Packard

Model

16Gb/28 SAN Switch for HP BladeSystem c-Class

Packaged Quantity

1

Product Line

Brocade

Interface Provided

Connector Type

SFP+

Qty

12

Type

16Gb Fibre Channel

Miscellaneous

Compliant Standards

AS/NZ 3548 Class A, BSMI CNS 13438 Class A, CISPR 22 Class A, CSA 22.2 No. 60950, EMC, EN 60950, EN55022 Class A, FCC CFR47 Part 15 B, FCC Class A certified, LVD, NEMKO, UL 60950, VCCI Class A ITE

Networking

Features

Full duplex mode

Fibre Channel

FC-AL-2, FC-BB-2, FC-BB-3, FC-DA, FC-FLA, FC-FS, FC-FS-2, FC-GS-4, FC-GS-5, FC-IFR, FC-LS, FC-MI-2, FC-PI, FC-PI-2, FC-PI-4, FC-PLDA, FC-SB-3, FC-SW-3, FC-SW-4, FC-Tape, FC-VI, FCP-2

Form Factor

Plug-in module

Manageable

Yes

Ports Qty

28

Remote Management Protocol

HTTP, SMI-S, SNMP, Telnet

Subcategory

Fibre Channel and SAN

Subtype

Fibre Channel

Type

Switch

Performance

Type

Aggregate bandwidth

Value

896 Gbps

Ports

Qty

16

Type

16Gb Fibre Channel (internal)

Ports (2nd)

Qty

12

Type

16Gb Fibre Channel

Service

Support Details Full Contract Period

1 year

Support Details Location

On-site

Support Details Service Included

Parts and labor

Support Details Type

Limited warranty

Service & Support

Type

1 year warranty
