466482-B21 - Комплект опций HP BLc VC 8Gb FC с 24 портами

Dimensions & Weight

Depth

3.7 in

Height

1.1 in

Weight

2.8 lbs

Width

10.6 in

Environmental Parameters

Humidity Range Operating

10 - 90%

Max Operating Temperature

95 °F

Min Operating Temperature

50 °F

Header

Brand

HPE

Compatibility

PC

Manufacturer

HP CTO Server Avnet

Model

8Gb 24-Port Fibre Channel Module

Packaged Quantity

1

Product Line

HPE Virtual Connect

Interface Provided

Connector Type

SFP+

Interface

8Gb Fibre Channel

Qty

6

Miscellaneous

Compliant Standards

AS/NZ 3548 Class A, EN 60950-1, EN55022 Class A, FCC Part 15 A, MIC Class A, UL 60950-1, VCCI, WEEE

Networking

Connectivity Technology

Wired

Features

Auto-negotiation, Manageable

Fibre Channel

FC-AL, FC-AL-2, FC-FG, FC-FLA, FC-GS, FC-GS-2, FC-GS-3, FC-PH, FC-PH-2, FC-PH-3, FC-VI

Form Factor

Plug-in module

Ports Qty

24

Status Indicators

Link OK, Link/activity, Module locator, Port status

Subcategory

Fibre Channel and SAN

Subtype

Fibre Channel

Type

Switch

Ports

Qty

24

Type

8Gb Fibre Channel

Service

Support Details Full Contract Period

1 year

Support Details Location

On-site

Support Details Service Included

Parts and labor

Support Details Type

Limited warranty

Service & Support

Type

1 year warranty

Slot Required

Total Qty

1

Type

Expansion slot
