658247-B21 - Комплект опционального блейд-переключателя HP 6125G

Capacity

Type

IGMP groups

Value

1024

Dimensions & Weight

Depth

11.5 in

Height

3.7 in

Weight

4.19 lbs

Width

14.6 in

Environmental Parameters

Humidity Range Operating

5 - 95% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

158 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-40 °F

Flash Memory

Installed Size

256 MB

Header

Brand

HPE

Compatibility

PC

Manufacturer

Hewlett-Packard

Model

6125G Ethernet Blade Switch

Packaged Quantity

1

Product Line

HPE

Interface Provided

Comments

Management

Connector Type

SFP/SFP+

Qty

4

Type

1000Base-T

Miscellaneous

Authentication Method

RADIUS, Secure Shell v.2 (SSH2), TACACS+

Compliant Standards

AS/NZS 3548 Class A, EN 60950-1, EN55022, EN55024, FCC Class A certified, ICES-003 Class A, MIC, RoHS 6/6, UL 60950-1, VCCI Class A ITE, WEEE

Networking

Advanced Switching

Layer 3

Compliant Standards

IEEE 802.1ag, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3x

Features

Access Control List (ACL) support, Auto-uplink (auto MDI/MDI-X), BOOTP support, DHCP client, DHCP protection, Dynamic VLAN Support (GVRP), Endpoint Admission Defense (EAD), IGMP snooping, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Rapid Spanning Tree Protocol (RSTP) support, sFlow, Spanning Tree Protocol (STP) support, Store and forward, STP Root Guard, Syslog support, Trivial File Transfer Protocol (TFTP) support, Unicast Reverse Path Forwarding (URPF), Virtual Route Redundancy Protocol (VRRP) support

Form Factor

Plug-in module

Jumbo Frame Support

9220 bytes

MAC Address Table Size

32K entries

Manageable

Yes

Ports Qty

8

Remote Management Protocol

CLI, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, SSH-2

Routing Protocol

BGP, ECMP, IGMP, IGMPv3, MSDP, OSPF, PIM-DM, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing, VRRP

Stackable

Stackable

Status Indicators

Link/activity, Port transmission speed

Subcategory

Network hubs and switches

Subtype

Gigabit Ethernet

Type

Switch

Ports

Qty

4

Type

10/100/1000

Ports (2nd)

Qty

2

Type

Gigabit SFP

Ports (3rd)

Qty

2

Type

Gigabit SFP / 10 Gigabit SFP+

RAM

Installed Size

1 GB
