571956-B21 - HP BLc VC FlexFabric 10 Гбит / с / 24 порта, опция

Dimensions & Weight

Depth

7.6 in

Height

1.1 in

Weight

2.8 lbs

Width

10.6 in

Environmental Parameters

Humidity Range Operating

10 - 90%

Max Operating Temperature

95 °F

Min Operating Temperature

50 °F

Header

Brand

HPE

Compatibility

PC

Manufacturer

HP CTO Server Avnet

Model

FlexFabric 10Gb/24-Port Module

Packaged Quantity

1

Product Line

HPE Virtual Connect

Interface Provided

Connector Type

SFP+

Qty

4

Type

8Gb Fibre Channel

Miscellaneous

Compliant Standards

AS/NZ 3548 Class A, CB, CISPR 22 Class A, CSA C22.2 No. 60950-1, cUL, EN 60950-1, EN55022 Class A, FCC Part 15 A, IEC 60950-1, MIC Class A, TUV, UL, UL 60950-1, VCCI Class A ITE, WEEE

Encryption Algorithm

SSL

Miscellaneous (CDW)

Compatible With

HPE BLc7000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment Trial Licenses, HPE BLc7000 Single-Phase Enclosure W/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses, HPE BLc7000 Three-Phase Enclosure W/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses, HPE Integrity BL860c i4, HPE ProLiant BL280c G6, HPE ProLiant BL2x220c G6, HPE ProLiant BL2x220c G6 Server A, HPE ProLiant BL2x220c G6 Server B, HPE ProLiant BL460c G6, HPE ProLiant BL465c g6, HPE ProLiant BL490c G6, HPE ProLiant BL495c G6, HPE ProLiant BL685c G6

Networking

Compliant Standards

IEEE 802.1Q, IEEE 802.2, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3aq

Features

Auto-negotiation, IGMP snooping, LDAP support, Manageable, VLAN support, Wake on LAN (WOL)

Fibre Channel

FC-AL, FC-AL-2, FC-FG, FC-FLA, FC-GS, FC-GS-2, FC-GS-3, FC-PH, FC-PH-2, FC-PH-3, FC-VI

Form Factor

Plug-in module

MAC Address Table Size

8K entries

Ports Qty

24

Remote Management Protocol

CLI, HTTP, HTTPS, SNMP 1, SNMP 2

Routing Protocol

IGMP, IGMPv2

Status Indicators

Link OK, Link/activity, Module locator, Port status

Subcategory

Network hubs and switches

Subtype

10 Gigabit Ethernet

Type

Switch

Ports

Qty

16

Type

10Gb Ethernet (backplane)

Ports (2nd)

Qty

4

Type

10Gb Ethernet/8Gb Fibre Channel SFP+

Ports (3rd)

Qty

4

Type

10Gb Ethernet SFP+
