AJ822C - Коммутатор HP 8 / 24c BladeSystem Pwr Pk + SAN

Compatibility Information

Designed For

HPE ProLiant c3000

Dimensions & Weight

Depth

11.8 in

Height

3.4 in

Weight

3.99 lbs

Width

15 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Humidity Range Storage

5 - 95% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

140 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-22 °F

Expansion / Connectivity

Installed Modules Qty (Max)

4 (installed) / 8 (max)

Interfaces

16 x 8Gb Fibre Channel ¦ 4 x 8Gb Fibre Channel SFP+ ¦ 4 x 8Gb Fibre Channel

General

Device Type

Switch - 24 ports - managed

Enclosure Type

Plug-in module

Features

ARP support, manageable, full duplex mode

Fibre Channel

FC-AL-2, FC-DA, FC-FLA, FC-FS, FC-GS-4, FC-PI, FC-PLDA, FC-SB-3, FC-SW-3, FC-Tape, FC-VI, FC-BB-2, FCP-2, FC-PI-2, FC-BB-3, FC-FS-2, FC-GS-5, FC-SW-4, FC-LS, FC-MI-2, FC-PI-4

Ports

16 x 8Gb Fibre Channel + 8 x 8Gb Fibre Channel SFP+

Remote Management Protocol

SNMP, Telnet, HTTP, SMI-S

Subtype

Fibre Channel

Manufacturer Warranty

Service & Support

Limited warranty - parts and labor - 1 year - on-site

Miscellaneous

Compliant Standards

FCC Class A certified, TUV, CISPR 22 Class A, BSMI CNS 13438 Class A, EN 60950, NEMKO, VCCI Class A ITE, EN55022 Class A, UL 60950, CSA 22.2 No. 60950, AS/NZ 3548 Class A, EMC, FCC CFR47 Part 15 B, RoHS2

Included Accessories

4 x 8 Gbps Short Wave Fibre Channel SFP+

Software / System Requirements

Software Included

Brocade Fabric Watch, Brocade Advanced Performance Monitoring, Brocade Extended Fabrics, Brocade ISL Trunking, Brocade Adaptive Networking
