AJ821C - Коммутатор HP BladeSystem 8 / 24c SAN серии B

Dimensions & Weight

Depth

11 in

Height

1.1 in

Weight

2.91 lbs

Width

7.6 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Humidity Range Storage

5 - 95% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

140 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-22 °F

Header

Brand

Brocade

Compatibility

PC

Manufacturer

Hewlett-Packard

Model

8/24c

Packaged Quantity

1

Product Line

Brocade 8Gb SAN Switch

Interface Provided

Connector Type

SFP+

Qty

4

Type

8Gb Fibre Channel

Miscellaneous

Color Category

Gray

Compliant Standards

AS/NZ 3548 Class A, BSMI CNS 13438 Class A, CISPR 22 Class A, CSA 22.2 No. 60950, EMC, EN 60950, EN55022 Class A, FCC CFR47 Part 15 B, FCC Class A certified, NEMKO, RoHS2, TUV, UL 60950, VCCI Class A ITE

Included Accessories

4 x 8 Gbps Short Wave Fibre Channel SFP+

Networking

Features

ARP support, Full duplex mode

Fibre Channel

FC-AL-2, FC-BB-2, FC-BB-3, FC-DA, FC-FLA, FC-FS, FC-FS-2, FC-GS-4, FC-GS-5, FC-LS, FC-MI-2, FC-PI, FC-PI-2, FC-PI-4, FC-PLDA, FC-SB-3, FC-SW-3, FC-SW-4, FC-Tape, FC-VI, FCP-2

Form Factor

Plug-in module

Manageable

Yes

Ports Qty

24

Remote Management Protocol

HTTP, SMI-S, SNMP, Telnet

Subcategory

Fibre Channel and SAN

Subtype

Fibre Channel

Type

Switch

Ports

Qty

16

Type

8Gb Fibre Channel (backplane)

Ports (2nd)

Qty

8

Type

8Gb Fibre Channel SFP+

Service

Support Details Full Contract Period

1 year

Support Details Location

On-site

Support Details Service Included

Parts and labor

Support Details Type

Limited warranty

Service & Support

Type

1 year warranty
