658250-B21 - Комплект опционального блейд-переключателя HP 6125G / XG

Capacity

Type

IGMP groups

Value

1024

Dimensions & Weight

Depth

10.5 in

Height

1.1 in

Weight

2.91 lbs

Width

7.6 in

Environmental Parameters

Humidity Range Operating

5 - 95% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

158 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-40 °F

Flash Memory

Installed Size

256 MB

Header

Brand

HPE

Compatibility

PC

Manufacturer

HP CTO Server Avnet

Model

6125G/XG Ethernet Blade Switch

Packaged Quantity

1

Product Line

HPE

Interface Provided

Comments

Management

Connector Type

SFP+

Interface

Ethernet 1000

Qty

4

Type

1000Base-T

Miscellaneous

Authentication Method

RADIUS, Secure Shell v.2 (SSH2), TACACS+

Compliant Standards

AS/NZS 3548 Class A, CAN/CSA C22.2 No. 60950-1, EN 60950-1, EN55022, EN55024, FCC Class A certified, MIC, RoHS 6/6, UL, UL 60950-1, VCCI Class A ITE, WEEE

Networking

Compliant Standards

IEEE 802.1ag, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3x

Features

Access Control List (ACL) support, ARP support, Auto-uplink (auto MDI/MDI-X), BOOTP support, Committed Access Rate (CAR), Device Link Detection Protocol (DLDP) support, DHCP client, DHCP protection, Dynamic ARP protection, Dynamic VLAN Support (GVRP), Endpoint Admission Defense (EAD), Flow control, IGMP snooping, IPv4 support, IPv6 support, Jumbo Frames support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Quality of Service (QoS), Rapid Ring Protection Protocol (RRPP) support, Rapid Spanning Tree Protocol (RSTP) support, sFlow, Spanning Tree Protocol (STP) support, Store and forward, STP Root Guard, Syslog support, Trivial File Transfer Protocol (TFTP) support, Trunking, Tunneling, Unicast Reverse Path Forwarding (URPF), Virtual Route Redundancy Protocol (VRRP) support, VLAN support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Weighted Round Robin (WRR) queuing

Form Factor

Plug-in module

Jumbo Frame Support

9220 bytes

MAC Address Table Size

32K entries

Manageable

Yes

Ports Qty

8

Remote Management Protocol

CLI, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, SSH-2

Routing Protocol

BGP, BGP-4, ECMP, IGMP, IGMPv3, MSDP, OSPF, OSPFv3, PIM-DM, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP

Stackable

Stackable

Status Indicators

Link/activity, Unit ID

Subcategory

Network hubs and switches

Subtype

Gigabit Ethernet

Type

Switch

Ports

Qty

4

Type

10/100/1000

Ports (2nd)

Qty

4

Type

Gigabit SFP / 10 Gigabit SFP+

RAM

Installed Size

1 GB
