657787-B21 - HP BLc Cisco B22HP Fabric Ext с 16 полевыми транзисторами

Capacity

Type

ACL entries

Value

256

Dimensions & Weight

Depth

3.7 in

Height

1.1 in

Weight

2.8 lbs

Width

10.6 in

Environmental Parameters

Humidity Range Operating

10 - 95% (non-condensing)

Max Operating Temperature

104 °F

Min Operating Temperature

50 °F

Expansion Slots

Type

SFP+

Header

Brand

Cisco

Compatibility

PC

Manufacturer

Hewlett-Packard

Model

B22HP

Packaged Quantity

1

Product Line

Cisco

Interface Provided

Connector Type

Backplane

Interface

10Gb Ethernet / Fibre Channel over Ethernet (FCoE)

Qty

16

Type

10Gb Ethernet / FCoE

Miscellaneous

Compliant Standards

AS/NZS 3548 Class A, BSMI Class A, CB, CISPR 22 Class A, CSA C22.2 No. 60950-1, EN55022 Class A, FCC Part 15 A, IEC 60950-1, KCC Class A, UL 60950-1, VCCI Class A ITE, WEEE

Included Accessories

16 Fabric Extender transceivers

Networking

Auxiliary Ports

8 x SFP+ (uplink)

Compliant Standards

IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ae, IEEE 802.3ap, IEEE 802.3x

Connectivity Technology

Wired

Data Link Protocol

10 Gigabit Ethernet, Fibre Channel over Ethernet (FCoE), Gigabit Ethernet

Data Transfer Rate

10 Gbps

Features

Access Control List (ACL) support, Auto-negotiation, Flow control, Jumbo Frames support, Quality of Service (QoS), Syslog support, VLAN support, Weighted Round Robin (WRR) queuing

Form Factor

Plug-in module

Network Transport Protocol

iSCSI

Ports Qty

16

Remote Management Protocol

CLI, RMON, SNMP 1, SNMP 2, SNMP 3

Status Indicators

Port status

Type

Expansion module

Power Device

Power Consumption Operational

70 Watt

Slot Provided

Free Qty

8

Total Qty

8

Slot Required

Total Qty

1

Type

Expansion slot
