638526-B21 - Опция модуля HP BLc VC Flex-10 / 10D

Capacity

Type

MAC addresses

Value

128000

Dimensions & Weight

Depth

10.5 in

Height

1.1 in

Weight

2.8 lbs

Width

3.7 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Max Operating Temperature

95 °F

Min Operating Temperature

50 °F

Hard Drive (2nd)

Type

None

Header

Brand

HPE

Compatibility

PC

Manufacturer

HP CTO Server Avnet

Model

Flex-10/10D Module

Packaged Quantity

1

Product Line

HPE Virtual Connect

Interface Provided

Connector Type

SFP+

Interface

10Gb Ethernet

Qty

4

Type

Network stack device

Miscellaneous

Authentication Method

RADIUS, TACACS+

Compliant Standards

AS/NZS 3548 Class A, CB, CISPR 22 Class A, CSA C22.2 No. 60950-1, cUL, EN 60950-1, EN55022 Class A, FCC Class A certified, FCC Part 15, MIC Class A, TUV, UL, UL 60950-1, VCCI Class A, WEEE

Encryption Algorithm

SSL

Miscellaneous (CDW)

Compatible With

HPE BLc3000 Enclosure W/2 Power Supplies and 4 Fans, HPE BLc3000 Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment 30 Day Evaluation Licenses, HPE BLc3000 Enclosure W/2 Power Supplies and 4 Fans with Insight Control Environment for BladeSystem Licenses, HPE BLc3000 Enclosure W/2 Power Supplies and 4 Fans with Insight Control Environment Licenses, HPE BLc3000 Enclosure W/2 Power Supplies and 4 Fans with Insight Control Environment Trial Licenses, HPE BLc3000 Enclosure W/4 Power Supplies and 6 Fans with Insight Control Environment Trial License, HPE BLc3000 Enclosure W/6 Power Supplies and 6 Fans with 8 Insight Control Licenses, HPE BLc3000 Enclosure With 8 Insight Control Environment 30 Day Trial Licenses, HPE BLc3000 Enclosure With 8 Insight Control Environment for BladeSystem Licenses, HPE BLc3000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment 30 Day Evaluation Licenses, HPE BLc3000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment Licenses, HPE BLc3000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment Trial Licenses, HPE BLc3000 Single-Phase Enclosure W/4 Power Supplies and 6 Fans w/8 Insight Control Environment Licenses, HPE BLc3000 Single-Phase Enclosure W/4 Power Supplies and 6 Fans w/8 Insight Control Environment Trial Licenses, HPE BLc3000 Single-Phase Enclosure W/4 Power Supplies and 8 Fans w/8 Insight Control Environment Licenses, HPE BLc7000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/16 Insight Control Env. Linux Edition Licenses, HPE BLc7000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/16 Insight Control Environment Licenses, HPE BLc7000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/16 Insight Control Tower Licenses, HPE BLc7000 Single-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment Trial Licenses, HPE BLc7000 Single-Phase Enclosure W/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses, HPE BLc7000 Three-Phase Enclosure W/2 Power Supplies and 4 Fans w/8 Insight Control Environment Trial Licenses, HPE BLc7000 Three-Phase Enclosure W/6 Power Supplies and 10 Fans w/16 Insight Control Environment Licenses, HPE BLc7000 Three-Phase Enclosure W/6 Power Supplies and 6 Fans w/16 Insight Control Environment Licenses, HPE BLc7000 Three-Phase Enclosure W/6 Power Supplies and 6 Fans w/8 Insight Control Environment Trial Licenses, HPE ProLiant C3000

Modem

Type

None

Networking

Communication Mode

Full-duplex

Compliant Standards

IEEE 802.1ab (LLDP), IEEE 802.1Q, IEEE 802.2, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ak, IEEE 802.3aq

Connectivity Technology

Wired

Data Link Protocol

10 Gigabit Ethernet

Data Transfer Rate

10 Gbps

Features

Firmware upgradable, IGMP snooping, Jumbo Frames support, LDAP support, Link Aggregation Control Protocol (LACP), Manageable, Stackable, VLAN support

Form Factor

Plug-in module

Network Transport Protocol

iSCSI

Remote Management Protocol

CLI, SNMP 1, SNMP 2

Routing Protocol

IGMP, IGMPv2, IGMPv3

Type

Load balancing device

Optical Storage

Type

None

Slot Required

Total Qty

1

Type

Expansion slot

Software

Type

HP Virtual Connect Manager
