J9421A - Контроллер HP MSM760

J9421A Specifications

AC voltage

100 - 240 V ac

Current

2/1 A

Dimensions (W x D x H)

43.99 x 39.07 x 4.45 cm (17.32 x 15.38 x 1.75 in) (1U height)

Emissions

FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003

Features

Supported:SupportedIEEE 802.11 n/a/b/g access points and/or access devices40 to 200 access points and/or access devices (in increments of 10 or 40)MSM firmware releases prior to MSM v5.7: 1,000 simultaneous guest access users upgradable in increments of 250 per 40-AP license pack, up to a maximum of 2,000 guest access users unlimited simultaneous usersMSM v5.7 and later: 2,000 simultaneous guest access users with base productIncluded services:Plug-and-play AP management and WLAN managementGuest accessCaptive portalPCI DSS compliance for wireless PoS trafficSupport for Real-Time Location Services (RTLS)Standard Layer 2 roaming with VoWLAN supportSupport for up to 16 VSC profiles Unified policy enforcement and network visibility

Frequency

50/60 Hz

Maximum heat dissipation

457.87 kJ/hr (434 BTU/hr)

Maximum power rating

127 W

Mounting and enclosure

Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (hardware included); horizontal surface mounting only

Nonoperating/Storage relative humidity

15% to 80%, noncondensing

Nonoperating/Storage temperature

-40° to 65°C (-40° to 149°F)

Operating relative humidity

15% to 80%, noncondensing

Operating temperature

5° to 40°C (41° to 104°F)

Ports

· 2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only· 1 RJ-45 serial console port

Safety

UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1

Type

HP MSM760 Access Controller

Weight

6.1 kg (13.45 lb)
