J9420A - Контроллер HP MSM760

J9420A Specifications

AC voltage

100 - 240 V ac

Current

2/1 A

Dimensions (W x D x H)

43.99 x 39.07 x 4.45 cm (17.32 x 15.38 x 1.75 in) (1U height)

Emissions

FCC part 15 Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003

Features

Supported:SupportedIEEE 802.11 n/a/b/g access points and/or access devices40 to 200 access points and/or access devices (in increments of 10 or 40)MSM firmware releases prior to MSM v5.7: 1,000 simultaneous guest access users upgradable in increments of 250 per 40-AP license pack, up to a maximum of 2,000 guest access users unlimited simultaneous usersMSM v5.7 and later: 2,000 simultaneous guest access users with base productIncluded services:Plug-and-play AP management and WLAN managementGuest accessCaptive portalPCI DSS compliance for wireless PoS trafficSupport for Real-Time Location Services (RTLS)Advanced fast roaming with VoWLAN supportMobility Traffic Manager (MTM)Support for up to 64 VSC profilesUnified policy enforcement and network visibilityVirtual controller (up to five MSM765 zl controllers and 800 APs with resiliency)

Frequency

50/60 Hz

Maximum heat dissipation

457.87 kJ/hr (434 BTU/hr)

Maximum power rating

127 W

Mounting and enclosure

Mounts in an EIA-standard 19-inch telco rack or equipment cabinet (hardware included); horizontal surface mounting only

Nonoperating/Storage relative humidity

15% to 80%, noncondensing

Nonoperating/Storage temperature

-40° to 65°C (-40° to 149°F)

Operating relative humidity

15% to 80%, noncondensing

Operating temperature

5° to 40°C (41° to 104°F)

Ports

· 2 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only· 1 RJ-45 serial console port

Safety

UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1

Type

HP MSM760 Premium Mobility Controller

Weight

6.1 kg (13.45 lb)
