Система Хранения HP MSA 2040 LFF Modular Smart Array Enclosure Chassis 12xSAS/SATA LFF 3,5'' 0(2)xController 2x595Wt 2U(K2R82A)

Bay Provided

Form Factor

3.5 LFF

Free Qty

12

Total Qty

12

Chassis

Installed Devices Modules Qty

0

Supported Devices Modules Qty

12

Supported Interface

Serial Attached SCSI 2

Dimensions & Weight

Depth

22.5 in

Height

3.5 in

Width

17.6 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Max Operating Temperature

104 °F

Min Operating Temperature

41 °F

Environmental Standards

ENERGY STAR Certified

Yes

Expansion Bays

Form Factor (metric)

8.9 cm LFF

Hard Drive

Type

No HDD

Header

Brand

HPE

Compatibility

PC, Unix

Manufacturer

Hewlett-Packard

Model

2040 LFF Chassis

Packaged Quantity

1

Product Line

HPE Modular Smart Array

Miscellaneous

Compliant Standards

BSMI CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1-03, CCC, CISPR 22 Class A, CISPR 24, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55022 Class A, EN55024 Class A, FCC Part 15 A, GS, ICES-003 Class A, IEC 60950-1, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE

Height (Rack Units)

2

Optical Storage

Type

None

Power Device

Frequency Required

50/60 Hz

Hot-Plug

Hot-plug

Installed Qty

2

Max Supported Qty

2

Nominal Voltage

AC 120/230 V

Power Redundancy

Yes

Power Redundancy Scheme

1+1

Type

Internal power supply

Processor

Type

None

Service

Support Details Full Contract Period

3 years

Support Details Service Included

Parts

Support Details Type

Limited warranty

Service & Support

Type

3 years warranty

Storage

Max Supported Capacity

96 TB

Maximum LUNs

512

Rack-mountable

Rack-mountable

Type

Storage enclosure

Storage Controller

Type

None

Storage Controller (2nd)

Type

None

System Requirements

Min Operating System

HP-UX, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Red Hat Linux, SUSE Linux Enterprise Server
