846633-B21 - Серверные сетевые контроллеры HPE

Dimensions & Weight

Depth

11.9 in

Height

0.9 in

Weight

3.81 lbs

Width

8.6 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

140 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-22 °F

Expansion / Connectivity

Interfaces

4 x 10Gbit/40Gbit LAN QSFP ¦ 2 x 1/10Gbit LAN SFP+ ¦ 1 x console RJ-45

General

Authentication Method

RADIUS, TACACS

Capacity

VLAN IDs: 4094 ¦ IGMP groups: 1024

Compliant Standards

IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1v, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qbg, IEEE 802.1r

Device Type

Switch - L3 - managed

Enclosure Type

Plug-in module

Encryption Algorithm

IKE

Features

BOOTP support, port mirroring, IPv6 support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Per-VLAN Spanning Tree (PVST), Multiple Spanning Tree Protocol (MSTP) support, Data Center Bridging Exchange (DCBX) support, Quality of Service (QoS), Committed Access Rate (CAR), Jumbo Frames support, Equal-Cost Multipath (ECMP), Endpoint Admission Defense (EAD), LLDP support, Management Information Base (MIB), dynamic ARP protection, Multiple VLAN Registration Protocol (MVRP), NTP time synchronization, Strict Priority (SP), sFlow v5, Intelligent Resilient Framework Technology (IRF), Type of Service (ToS), Virtual Private LAN Service (VPLS), system log, IP source guard, Shortest Path Bridging (SPB), Internet Control Message Protocol (ICMP), NPV Gateway mode, Transparent Interconnection of Lots of Links (TRILL), Virtual Extensible LAN (VXLAN), Software Defined Networking (SDN), policy based routing, User Datagram Protocol (UDP), PVLAN edge, Protocol Independent Multicast (PIM), Weighted Round Robin (WRR)

Flash Memory

512 MB

Jumbo Frame Support

10KB

MAC Address Table Size

288K entries

Performance

Uplink bandwidth: 180 Gbps ¦ Bandwidth: 240 Gbps ¦ Throughput: 1.2 Tbps ¦ Latency: 1.3 µs

Ports

4 x QSFP + 2 x SFP+

RAM

2 GB

Remote Management Protocol

SNMP 1, SNMP 2, SNMP, SNMP 3, SNMP 2c, HTTPS, SSH, SSH-2

Routing Protocol

OSPF, RIP, RIP-1, RIP-2, BGP, IGMP, VRRP, IGMPv3, OSPFv3, MSDP, ECMP, MPLS, CIDR, BGP+, URPF

Status Indicators

Power, link OK, link/activity

Subtype

40 Gigabit Ethernet

Manufacturer Warranty

Service & Support

Limited warranty - parts and labor - 3 years - on-site

Miscellaneous

Compliant Standards

FCC Class A certified, ICES-003 Class A, AS/NZS 3548 Class A, VCCI Class A, IPsec/IKE

Power

Power Consumption Operational

112 Watt
