843400-B21 - Серверные сетевые контроллеры HPE

Compatibility Information

Designed For

HPE ProLiant XL230k Gen10 Compute Tray, XL260a Gen9, XL260a Gen9 Compute Tray

General

Device Type

Network adapter

Interface (Bus) Type

PCI Express 3.0 x16 Mezzanine

PCI Specification Revision

PCIe 3.0

Manufacturer Warranty

Service & Support

Limited warranty - parts - 1 year

Miscellaneous

Compliant Standards

EN55024, EN55022 Class A, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, IEC 60068-2-32, RoHS, FCC Part 15 A, IEC 60068-2-29, IEC 60068-2-64, CAN/CSA C22.2 No. 60950-1, KC, VCCI Class A, AS/NZS CISPR22:2006 Class A

Pricing Type

Factory integrated

Networking

Compliant Standards

IBTA 1.3

Connectivity Technology

Wired

Data Link Protocol

InfiniBand

Data Transfer Rate

100 Gbps

Features

PXE support, UEFI support, InfiniBand EDR Link support, Extended Reliable Connected transport (XRC), Dynamically Connected transport (DCT), user mode registration and remapping of memory (UMR), On demand paging (ODP)

Ports

Infiniband EDR x 2

Processor / Memory

Processor

1 x Mellanox ConnectX-4

Software / System Requirements

OS Required

SuSE Linux Enterprise Server 12 SP1, CentOS 7.2 (64-bit), Red Hat Enterprise Linux 7.2 (64-bit)
