817753-B21 - Сетевые адаптеры для сервера HPE

Capacity

Type

Jumbo frame size

Value

Up to 9.6 KB

Environmental Parameters

Humidity Range Operating

5 - 95% (non-condensing)

Max Operating Temperature

140 °F

Min Operating Temperature

41 °F

Header

Brand

HPE

Compatibility

PC, Unix

Manufacturer

Hewlett-Packard

Model

640SFP28

Packaged Quantity

1

Product Line

HPE

Interface Provided

Connector Type

SFP28

Qty

2

Type

25Gb Ethernet

Miscellaneous

Compliant Standards

ACA, BSMI Class A, CISPR 22 Class A, cTUVus, EN 55022 Class A, EN 60950-1, EN55024, FCC Class A certified, ICES-003, RoHS 6/6, VCCI Class A

Networking

Compliant Standards

IEEE 1588v2, IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3x

Connectivity Technology

Wired

Data Link Protocol

10 Gigabit Ethernet, 25 Gigabit Ethernet

Data Transfer Rate

25 Gbps

Features

Extended Message-Signaled Interrupts (MSI-X), Full duplex mode, IPv4 support, IPv6 support, Jumbo Frames support, LACP support, Large Send Offload (LSO), LLDP support, Network Virtualization using Generic Routing Encapsulation (NVGRE), PXE support, QoS tagging, Quality of Service (QoS), RDMA over Converged Ethernet (RoCE), RDMA over Converged Ethernet (RoCE) v2, Receive Side Scaling (RSS), TCP Segmentation Offload (TSO), TCP/IP checksum offload, TCP/IP offloading, UDP/IP offloading, UEFI support, Virtual Extensible LAN (VXLAN), VLAN support

Form Factor

Plug-in card

Interface Type

PCI Express 3.0 x8 / PCI Express 3.0 x4

Low Profile

Low profile

PCI Specification Revision

PCIe 3.0

Remote Management Protocol

SNMP

Status Indicators

Link/activity

Type

Network adapter

Performance

Type

Bidirectional throughput

Value

100 Gbps

Ports

Qty

2

Type

25 Gigabit Ethernet

Power Device

Power Consumption Operational

9.7 Watt

Processor

Installed Qty

1

Manufacturer

Mellanox Technologies

Type

Mellanox ConnectX-4 Lx

Service

Support Details Full Contract Period

1 year

Support Details Type

Limited warranty

Service & Support

Type

1 year warranty

System Requirements

Min Operating System

Citrix XenServer 6.5, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Oracle Solaris 11.1, Red Hat Enterprise Linux 6.6, Red Hat Enterprise Linux 6.7, Red Hat Enterprise Linux 7, Red Hat Enterprise Linux 7.1, Red Hat Enterprise Linux 7.2, SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 12, Ubuntu 14.04, VMware ESXi 5.5, VMware ESXi 6.0
