787635-B21 - Комплект опционального блейд-переключателя HP 6127XLG

Capacity

Type

Virtual interfaces (VLANs)

Value

4094

Dimensions & Weight

Depth

10.5 in

Height

1.1 in

Weight

4.41 lbs

Width

7.6 in

Environmental Parameters

Humidity Range Operating

10 - 90% (non-condensing)

Max Operating Temperature

95 °F

Max Storage Temperature

158 °F

Min Operating Temperature

50 °F

Min Storage Temperature

-40 °F

Flash Memory

Installed Size

512 MB

Header

Brand

HPE

Compatibility

PC

Manufacturer

ProCurve Networking

Model

6127XLG Ethernet Blade Switch

Packaged Quantity

1

Product Line

HPE

Interface Provided

Comments

Management

Connector Type

SFP+

Qty

8

Type

10Gbit LAN

Miscellaneous

Authentication Method

RADIUS, Secure Shell v.2 (SSH2), TACACS+

Color Category

Gray

Compliant Standards

AS/NZS 3548 Class A, BSMI CNS 13438 Class A, CAN/CSA C22.2 No. 60950-1, CISPR 22, CISPR 24, EN 60950-1, FCC Class A certified, FCC Part 15 A, ICES-003 Class A, IPsec/IKE, IPv6 Ready, MIC, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE

Encryption Algorithm

IKE

Networking

Advanced Switching

Layer 3

Compliant Standards

IEEE 1588v2, IEEE 802.1ag, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1Qbg, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ag, IEEE 802.3ah

Features

802.1x authentication, Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-sensing per device, Auto-uplink (auto MDI/MDI-X), BOOTP support, Committed Access Rate (CAR), Data Center Bridging Exchange (DCBX) support, Device Link Detection Protocol (DLDP) support, DHCP protection, DHCP support, DiffServ Code Point (DSCP) support, Dynamic ARP protection, Endpoint Admission Defense (EAD), FCoE support, Fibre Channel Forwarder (FCF), Flow control, Full duplex mode, GARP VLAN Registration Protocol (GVRP), ICMP Router Discovery Protocol (IRDP), Ingress Layer 2 MAC Access Control Lists (ACLs), Intelligent Resilient Framework Technology (IRF), IP source guard, IPSec passthrough, IPv6 support, Jumbo Frames support, Layer 2 switching, Link Aggregation Control Protocol (LACP), LLDP support, Management Information Base (MIB), Maximum Likelihood Demodulation (MLD), MLD snooping, Multicast Source Discovery Protocol (MSDP), Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), NPV Gateway mode, Per-VLAN Spanning Tree (PVST), Port mirroring, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, sFlow, Shortest Path Bridging (SPB), Static routing, STP Root Guard, Strict Priority (SP), Syslog support, Transparent Interconnection of Lots of Links (TRILL), Tunneling, Type of Service (ToS), Unicast Reverse Path Forwarding (URPF), Virtual Ethernet Port Aggregator (VEPA), Virtual Extensible LAN (VXLAN), Virtual Route Redundancy Protocol (VRRP) support, VLAN support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Weighted Round Robin (WRR) queuing

Form Factor

Plug-in module

Jumbo Frame Support

10000 bytes

MAC Address Table Size

128K entries

Manageable

Yes

Ports Qty

12

Remote Management Protocol

HTTPS, SNMP, SNMP 1, SNMP 2, SNMP 3, SSH-2, Telnet, TFTP

Routing Protocol

BGP, BGP+, BGP-4, Bidirectional PIM, CIDR, ECMP, IGMP, IGMPv3, MLD, MPLS, MSDP, OSPF, OSPFv3, PIM-DM, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP

Status Indicators

Link/activity, Unit ID

Subcategory

Network hubs and switches

Type

Switch

Performance

Type

Throughput

Value

59200000 packets per second

Ports

Qty

4

Type

40 Gigabit QSFP+

Ports (2nd)

Qty

8

Type

10 Gigabit SFP+

RAM

Installed Size

2 GB

Software

Type

HP Intelligent Management Center
